LUFTooL locking ring - 75 mm

Replacement actuator for the Distribute system and the automatic damper module. The actuator can be easily replaced with a new one. After installation, do not forget to calibrate.

The automatic damper module is part of the LUFTooL Distribute series. The damper enables automatic control and, together with other elements of the modular system, is used for zoning ventilation with heat recovery in family houses, apartments and small businesses. The system can be used for both supply and exhaust air with flow rates up to 100 m3/h in one branch. The LUFTooL Distribute system is: • an innovative system for distributing air flow into individual zones/rooms • modular (its components can be combined) • designed for flexible plastic pipes with a diameter of 75 and 90 mm and traditional SPIRO pipes of 100 mm • designed for ventilation in family houses and small businesses with air flows through individual branches up to 100 m3/h • a very tight system achieves tightness class D according to ČSN EN 15727 • suitable for the supply and exhaust of commonly polluted air (without chemicals, etc.) • fully cleanable, brushes can be pulled through the damper without dismantling the damper module • made of ABS and PETG The package contains: A plastic molding of the damper body (ABS) fitted with a damper blade and damper axis (PETG). A calibrated servo drive is mounted on the module body in the closed position. Instructions. Unlike the illustration, the package does not contain a blue cover. Packed in a plastic bag. The damper module can be screwed on one side, e.g. to: LUFTooL connectors (LF-CO-125) - which are inserted into the distribution box LUFTOMET® Flat boxes On the other hand, the module is ready for connection to LUFTooL pipe sockets: LT-SP-75-F....LUFTooL Spigot pipe socket (75 mm, female) LT-SP-90-F....LUFTooL Spigot pipe socket (90 mm, female) LT-SP-100-F....LUFTooL Spigot pipe socket (100 mm, female) (spout for traditional SPIRO pipes, white plastic or flexible SONO, Mastersan, etc. pipes, dimension 100 mm) Installation examples 1) installation via the connector to the distribution box - regulates the air flow coming out of the distribution box 2) installation in front of the LUFTOMET Flat box - regulates the air flow before the outlet Characteristics servo drive Operating voltage: 4.8 - 6.0 V Gear material: metal (first gear from the motor plastic) Dimensions: 23 x 12 x 29 mm Standing torque: 1.8 kg/cm (4.8 V); 2.2 kg/cm (6.0 V) Temperature range: 10 to +50°C Weight: 13.5 grams Wire length: 175 mm Rotation tolerance: ± 8% Controlling the damper module To control the damper module, you can purchase the LUFTaTOR API12 control module - this is software and a control board that allows you to control up to 12 dampers using the HTTP REST API. !!! In the case of control by your own system, the servo drive is not guaranteed. Basic requirements for system operation: - max. air flow through one fully open damper is 100 m3/h. Depending on the position of the damper and the percentage of its closure, the maximum allowed flow rate (LFmax) is reduced proportionally. The air flow rate through one or more distribution boxes (PBmax) generated by the heat recovery unit in one direction (supply/exhaust) must not exceed the sum of the maximum flows of all dampers PBmax < ΣLFmax - air temperature flowing through the damper 10-40°C - air temperature around the actuator and control board 10-40°C, humidity 30-90% RH - it is always necessary to maintain access to the control board and actuators for possible replacement Service To clean the piping system, the damper blade can be easily removed through a conveniently located service opening from the distribution box. To remove the damper axis and the outer part with the actuator, it is necessary to remove two screws using a Phillips screwdriver. The damper body and the neck do not need to be removed.

The connector is part of the LUFTooL Distribute system, which is innovative and modular. The entire system is designed for easy air regulation, thanks to which it is possible to freely distribute the air flow in individual zones or rooms in family houses and smaller businesses. However, individual elements can also be used for other elements such as ceiling and wall boxes. For example, the connector can be installed in any box with an appropriate opening. The LUFTooL Distribute system is: • an innovative system for distributing air flow into individual zones/rooms • modular (its components can be combined) • designed for flexible plastic pipes with a diameter of 75 and 90 mm and traditional SPIRO pipes of 100 mm • designed for ventilation in family houses and small businesses with air flows through individual branches up to 100 m3/h • a very tight system achieves class D tightness according to ČSN EN 15727 • suitable for the supply and exhaust of commonly polluted air (without chemicals, etc.) • fully cleanable, pulling brushes through the damper can be done without dismantling the damper module • made of ABS and PETG Package includes: Connector (PETG), two sealing rings. Packed in a plastic bag. Assembly: E.g. to: LUFTooL damper module with automatic or manual control LUFTooL pipe sockets (75, 90 and 100 mm) Installation examples Installation via connector or damper module to distribution box

The flexible pipe socket with an outer diameter of 90 mm is a universal modular element from the LUFTooL Distribute series. It consists of components that can be screwed together quickly and tightly into various units. The LUFTooL Distribute system is: • an innovative system for distributing air flow into individual zones/rooms • modular (its components can be combined) • designed for flexible plastic pipes with a diameter of 75 and 90 mm and traditional SPIRO pipes of 100 mm • designed for ventilation in family houses and small businesses with air flows through individual branches up to 100 m3/h • a very tight system achieves class D tightness according to ČSN EN 15727 • suitable for the supply and exhaust of commonly polluted air (without chemicals, etc.) • fully cleanable, pulling brushes through the damper can be done without dismantling the damper module • made of ABS and PETG Package includes: Plastic molding of the neck body (ABS), sealing and locking ring (PETG). Packed in a plastic bag. Dimensions: The spigot can be screwed on one side, for example, to: LUFTooL connectors (LF-CO-125) - which are inserted into the distribution box LUFTOMET® Flat boxes LUFTooL damper module with automatic or manual control Installation examples Mounting via connector or damper module to the distribution box Assembly Screw on the appropriate module. Then put the seal on the pipe, insert it into the spigot and lock it with the blue locking ring.
